Case IH Axial-Flow 7250

Specifications

  • Manufacturer: Case IH
  • Model: Axial-Flow 7250
  • Type: Combines
  • Size Class: 7
  • Horsepower, Rated Hp [ Kw ]: 402 [300]
  • Horsepower, Maximum Hp [ Kw ]: 468 [349]
  • Power Boost Hp [ Kw ]: 66 [49]
  • Engine Make: Case Ih Fpt
  • Engine Model: C11
  • Number Of Cylinders: 6
  • Piston Displacement Inches³ [ Ltr ]: 677 [11.1]
  • Fuel Tank Capacity Gallons (us) [ Ltr ]: 297 [1124]
  • Diesel Exhaust Fluid (def) Tank Capacity Gallons (us) [ Ltr ]: 43 [166]
  • Feeder Width Inches [ Mm ]: 54 [1372]
  • Feeder Speed Variable: Standard
  • Feeder Reverser Control: Electro-hydraulic
  • Feeder Tilt Adjustment: Fore-aft Std; Lateral Std.
  • Stone / Rock Protection: Spiral Beater/sump, Optional
  • Threshing System Type, Rotary Or Conventional Cylinder: Longitudinal Rotor
  • Number Of Rotors Or Cylinders: 1 Rotor
  • Rotor Or Cylinder Description: Staggered Rasp Bars
  • Rotor Or Cylinder Diameter Inches [ Mm ]: 30 [762]
  • Rotor Or Cylinder Length Inches [ Mm ]: 102.8 [2612]
  • Rotor Or Cylinder Speed Range - High Rpm: 1180
  • Rotor Or Cylinder Speed Range - Low Rpm: 220
  • Threshing Area Wrap °: 180
  • Concave Adjustment: Electronic, W/position Sensor
  • Total Sieve Area In² [ M² ]: 10075 [6.5]
  • Leveling System Available: Self-leveling To 12.1%
  • Cleaning Fan Description: 15.4" (391) Dia. Cross Flow
  • Cleaning Fan Speed Range - High Rpm: 1150
  • Cleaning Fan Speed Range - Low Rpm: 300
  • Grain Tank Capacity, Standard Bu (us) [ L ]: 315 [11100]
  • Optional Grain Tank Capacity Bu (us) [ L ]: 410 [14448]
  • Unloading Rate Bu (us)/s [ L/s ]: 4 [141]
  • Unloading Auger Length, Standard Ft/in [ M ]: 28 Ft 9 In [8.8]
  • Reference Drive Tire Size: If800/70r38
  • Steering Tire Size: Vf600/70 R28 Cfo, R1w
  • Rubber Tracks Available: 30" Or 36" Factory Fit
  • Weight Lbs [ Kg ]: 42245 [19162]
  • Wheelbase, 2wd Inches [ Mm ]: 148 [3759.21]
  • Transport Height Ft/in [ M ]: 13 Ft 1 In [4]
  • Optional Auger Length Ft/in [ M ]: 50 Ft [15.2]
