Case IH Axial-Flow 6150

Specifications

  • Manufacturer: Case IH
  • Model: Axial-Flow 6150
  • Type: Combines
  • Size Class: 6
  • Horsepower, Rated Hp [ Kw ]: 348 [259]
  • Horsepower, Maximum Hp [ Kw ]: 411 [306]
  • Power Boost Hp [ Kw ]: 63 [47]
  • Engine Make: Case Ih Fpt
  • Engine Model: C9
  • Number Of Cylinders: 6
  • Piston Displacement Inches³ [ Ltr ]: 531 [8.7]
  • Fuel Tank Capacity Gallons (us) [ Ltr ]: 250 [945]
  • Diesel Exhaust Fluid (def) Tank Capacity Gallons (us) [ Ltr ]: 43 [166]
  • Feeder Width Inches [ Mm ]: 45.5 [1156]
  • Feeder Speed Variable: 2 Speed
  • Feeder Reverser Control: Hydraulic
  • Feeder Tilt Adjustment: Fore-aft Std; Lateral Std.
  • Stone / Rock Protection: Beater/sump
  • Threshing System Type, Rotary Or Conventional Cylinder: Rotary
  • Number Of Rotors Or Cylinders: 1 Rotor
  • Rotor Or Cylinder Description: Staggered Rasp Bars
  • Rotor Or Cylinder Diameter Inches [ Mm ]: 30 [762]
  • Rotor Or Cylinder Length Inches [ Mm ]: 110 [2794]
  • Rotor Or Cylinder Speed Range - High Rpm: 1150
  • Rotor Or Cylinder Speed Range - Low Rpm: 250
  • Threshing Area Wrap °: 156.5
  • Concave Adjustment: Electronic, W/position Sensor
  • Total Sieve Area In² [ M² ]: 8556 [5.52]
  • Leveling System Available: Fixed Or Cross Flow
  • Cleaning Fan Description: Cross Flow
  • Cleaning Fan Speed Range - High Rpm: 1300
  • Cleaning Fan Speed Range - Low Rpm: 450
  • Grain Tank Capacity, Standard Bu (us) [ L ]: 300 [10570]
  • Unloading Rate Bu (us)/s [ L/s ]: 3.2 [113]
  • Unloading Auger Length, Standard Ft/in [ M ]: 25 Ft 10 In [7.86]
  • Reference Drive Tire Size: 800/65 R32
  • Steering Tire Size: Vf600/70 R28 Cfo, R1w
  • Rubber Tracks Available: No
  • Weight Lbs [ Kg ]: 34130 [15481]
  • Wheelbase, 2wd Inches [ Mm ]: 150.2 [3815]
  • Transport Height Ft/in [ M ]: 12 Ft 9 In [3.907]
