Case IH Precision Air 3915

Specifications

  • Manufacturer: Case IH
  • Model: Precision Air 3915
  • Type: Air Carts
  • Number Of Tanks/compartments: 3
  • Number Of Tanks/compartments: 3
  • Tow Position: Tow Between (tbt) Or Tow Behind (tbh): Behind
  • Total Capacity Bu (us) [ L ]: 915 [32224]
  • First Tank - Bu (l): 325 (11453)
  • First Tank Bu (us) [ L ]: 325 [11453]
  • Second Tank Bu (us) [ L ]: 170 [5991]
  • Third Tank - Bu (l): 420 (14800)
  • Tank Material, Steel Or Poly: Polyethylene Roto-molded
  • Meter Description: Variable Rate, Modular Cartridges
  • Meter Drive, Standard: Manual Control, Variable Rate
  • Meter Drive, Optional: Accusection Multi-segment
  • Fan Description: Dual Fan Double Shoot; Single Fan Single Shoot
  • Fan Drive: Hydraulic
  • Fill Auger Diameter - In (mm): Ksi Belt Conveyor, 88 Bu/min.
  • Front Tire Size: 800/70 R38 Single
  • Rear Single Tire Size: No Single Rear
  • Rear Dual Tire Size: 800/70 R38 Dual
  • Width, Single Tires - Ft-in (m): 21' 2" (6.45)
  • Width, Dual Tires Ft/in [ M ]: 21 Ft 2 In [6.45]
  • Height To Hand Rails Ft/in [ M ]: 17 Ft 6 In [5.33]
  • Overall Length Ft/in [ M ]: 46 Ft 8 In [14.22] (tbh)
  • Weight, Empty - Lb (kg): 29,979 (13598) (tbh)
  • Standard Monitor: Afs Pro 700
  • Optional Monitor: Iso 11783
  • Tank Level Sensors: Standard
  • Blockage Sensors: Optional On Air Drills
